Pic.	Niemöller part-no.	Designation		Price/unit excl. tax.
Image number 270		F 42 266 F 42 266	Parking brake Parking brake 116 420 09 84 or 1164200984		on request on request
Image number 272		F 42 271 F 42 271	Damper ring Damper ring 116 427 01 86 or 1164270186		on request on request
Image number 274		F 42 273 F 42 273	Brake pedal cover Brake pedal cover 107 427 00 82 or 1074270082		€12.15 €12.15
Image number 276		F 42 274 F 42 274	Tension spring Tension spring 115 993 26 10 or 1159932610		on request on request
Image number 280		F 42 282 F 42 282	Pull rod Pull rod 116 427 02 31 or 1164270231		on request on request
Image number 282		C 07 321 C 07 321	Washer Washer 000 125 006 449 or 000125006449		€0.78 €0.78
Image number 291		F 42 288 F 42 288	Damper ring Damper ring 115 427 03 86 or 1154270386		€1.50 €1.50
Image number 296		F 42 290 F 42 289	Knob Handle 107 420 00 95 or 1074200095		on request €49.00
	F 42 289	Replacement: Knob		€49.00
Image number 300		G 42 082 G 42 082	Hex nut Hex nut 913 012 006 001 or 913012006001		€12.35 €12.35
Image number 305		D 01 277 D 01 277	Hex. socket screw Hex. socket screw 000 912 006 066 or 000912006066		€1.10 €1.10
Image number 307		C 09 102 C 01 257	Washer Washer for damper reservoir 180 990 10 40 or 1809901040		on request €0.24
	C 01 257	Replacement: Washer		€0.24
Image number 309		G 22 020 G 22 020	Lock washer Lock washer 912 004 006 102 or 912004006102		€0.30 €0.30
Image number 315		F 42 326 F 42 326	Front brake cable Front brake cable 116 420 05 85 or 1164200585		on request on request
Image number 317		F 42 332 F 42 332	Spring clamp Spring clamp 115 993 03 25 or 1159930325		€17.77 €17.77
Image number 319		D 25 232 D 25 232	Hose Piece Pipeline to Coupling Housing Hose Piece Pipeline to Coupling Housing 110 997 08 82 or 1109970882		€1.50 €1.50
Image number 324		F 42 338 F 42 338	Brake arm Brake arm 116 420 04 42 or 1164200442		€134.67 €134.67
Image number 325		F 42 353 F 42 353	Bolts Bolts 115 427 09 74 or 1154270974		€1.56 €1.56
Image number 326		F 42 344 F 42 344	Shackle Shackle 123 420 05 89 or 1234200589		on request on request
Image number 328		F 42 350 F 42 350	Screw Screw 115 427 06 71 or 1154270671		€81.60 €81.60
Image number 330		F 42 351 F 42 351	Mounting support Mounting support 116 427 01 41 or 1164270141		€1.56 €1.56
Image number 333		F 42 367 F 42 367	Spring Spring 116 993 04 10 or 1169930410		on request on request
Image number 336		C 07 173 A 07 012	Split pin 1,6x22 DIN 94 for bearing bolt Split pin for connecting rod 1,5x12 000 094 001 503 or 000094001503		on request €0.90
	A 07 012	Replacement: Split pin 1,6x22 DIN 94 for bearing bolt		€0.90
Image number 337		F 42 332 F 42 332	Spring clamp Spring clamp 115 993 03 25 or 1159930325		€17.77 €17.77
Image number 338		F 42 331 F 42 331	Protective cap for front brake cable Protective cap for front brake cable 115 427 00 95 or 1154270095		€52.62 €52.62
Image number 340		F 42 333 F 42 333	Clamp Clamp 115 995 02 10 or 1159950210		€29.92 €29.92
Image number 348		F 88 014 F 88 014	Screw Screw 000 990 68 36 or 0009906836		€0.74 €0.74
Image number 350		F 42 374 F 42 374	Rear brake cable Rear brake cable 116 420 04 85 or 1164200485		€32.00 €32.00
Image number 353		G 42 148 G 42 148	Screw, brake cable on rear axle Screw, brake cable on rear axle 000 933 010 162 or 000933010162		€18.30 €18.30
Image number 355		G 35 012 G 35 012	Spring washer B 10x18 Spring washer B 10x18 000 137 010 205 or 000137010205		€0.85 €0.85
Image number 358		F 83 252 F 83 252	Grommet Grommet 115 997 06 81 or 1159970681		€3.22 €3.22

Please note that the product names may be an automatic translation for which no guarantee can be given.

in stock
low stock level
currently not in stock, but available for order
no longer available

Parking brake

F 42 266

Damper ring

F 42 271

Brake pedal cover

F 42 273 €12.15

Tension spring

F 42 274

Pull rod

F 42 282

Washer

C 07 321 €0.78

Damper ring

F 42 288 €1.50

Handle

F 42 290

Replacement item available

Hex nut

G 42 082 €12.35

Hex. socket screw

D 01 277 €1.10

Washer for damper reservoir

C 09 102

Replacement item available

Lock washer

G 22 020 €0.30

Front brake cable

F 42 326

Spring clamp

F 42 332 €17.77

Hose Piece Pipeline to Coupling Housing

D 25 232 €1.50

Brake arm

F 42 338 €134.67

Bolts

F 42 353 €1.56

Shackle

F 42 344

Screw

F 42 350 €81.60

Mounting support

F 42 351 €1.56

Spring

F 42 367

Split pin for connecting rod 1,5x12

C 07 173

Replacement item available

Spring clamp

F 42 332 €17.77

Protective cap for front brake cable

F 42 331 €52.62

Clamp

F 42 333 €29.92

Screw

F 88 014 €0.74

Rear brake cable

F 42 374 €32.00

Screw, brake cable on rear axle

G 42 148 €18.30

Spring washer B 10x18

G 35 012 €0.85

Grommet

F 83 252 €3.22

FROM CHASSIS:
020 053228 FEDERAL
020 053235 CALIFORNIA,
032 043640 FEDERAL
032 043677 CALIFORNIA,
033 043634 FEDERAL,
033 043561 CALIFORNIA,

Parking brake

F 42 266

FROM CHASSIS:
020 053228 FEDERAL
020 053235 CALIFORNIA,
032 043640 FEDERAL
032 043677 CALIFORNIA,
033 043634 FEDERAL
033 043561 CALIFORNIA,

Damper ring

F 42 271

UP TO CHASSIS:
020 053227, FEDERAL, EXCEPT FOR:
044616, 051531, 051953, 052007, 052021.
020 053234, CALIFORNIA, EXCEPT FOR: 051657
032 043639, FEDERAL, EXCEPT FOR:
042896, 043061, 043071, 043136, 043171, 043231, 043293, 043352, 043356, 043414, 043433, 043434.
032 043676, CALIFORNIA, EXCEPT FOR:
037501, 042716, 043185, 043244.
033 043633, FEDERAL, EXCEPT FOR:
032510, 032841, 042763, 042981, 043138, 043144, 043177, 043203, 043225, 043278, 043289, 043296, 043300, 043328,
043340, 043347, 043382, 043387, 043402, 043411, 043581, 043591, 043596, 043600, 043604, 043615, 043618, 043621,
043623, 043625, 043628, 043630.
033 043560, CALIFORNIA, EXCEPT FOR:
042932, 043174, 043228, 043251.

Hose Piece Pipeline to Coupling Housing

D 25 232 €1.50

FROM CHASSIS:
020 041520
032,033 037590

Rear brake cable

F 42 374 €32.00

Brake pedal cover

F 42 273 €12.15

Tension spring

F 42 274

Pull rod

F 42 282

Washer

C 07 321 €0.78

Damper ring

F 42 288 €1.50

Handle

F 42 290

Replacement item available

Hex nut

G 42 082 €12.35

Hex. socket screw

D 01 277 €1.10

Washer for damper reservoir

C 09 102

Replacement item available

Lock washer

G 22 020 €0.30

Front brake cable

F 42 326

Spring clamp

F 42 332 €17.77

Brake arm

F 42 338 €134.67

Bolts

F 42 353 €1.56

Shackle

F 42 344

Screw

F 42 350 €81.60

Mounting support

F 42 351 €1.56

Spring

F 42 367

Split pin for connecting rod 1,5x12

C 07 173

Replacement item available

Spring clamp

F 42 332 €17.77

Protective cap for front brake cable

F 42 331 €52.62

Clamp

F 42 333 €29.92

Screw

F 88 014 €0.74

Screw, brake cable on rear axle

G 42 148 €18.30

Spring washer B 10x18

G 35 012 €0.85

Grommet

F 83 252 €3.22
