Image number
1
|
|
C 88 189a
C 88 189a
|
Bonnet
Bonnet
10 120 880 02 57 or 101208800257
|
|
on request
on request
|
|
|
Image number
2
|
|
C 88 197a
C 88 197a
|
Hood hinge left
Hood hinge left
10 120 880 05 29 or 101208800529
|
|
€145.00
€145.00
|
|
|
Image number
3
|
|
C 88 194a
C 88 194a
|
Hood hinge, right
Hood hinge, right
10 120 880 06 29 or 101208800629
|
|
€145.00
€145.00
|
|
|
Image number
4
|
|
C 88 200a
C 88 200a
|
Tension spring
Tension spring
10 120 887 02 79 or 101208870279
|
|
on request
on request
|
|
|
Image number
6
|
|
C 88 204
C 88 204
|
Spring washer
Spring washer
002 093 020 102 or 002093020102
|
|
on request
on request
|
|
|
Image number
7
|
|
C 88 205
C 88 205
|
Spring washer for hood hinge
Spring washer for hood hinge
000 990 00 48 or 0009900048
|
|
on request
on request
|
|
|
Image number
5
|
|
C 88 202
C 88 202
|
Hex screw
Hex screw
000 984 03 33 or 0009840333
|
|
€19.00
€19.00
|
|
|
Image number
8
|
|
C 88 206a
C 09 087
|
Plate washer
Disc for hood hinge
10 120 887 04 58 or 101208870458
|
|
on request
€2.01
|
|
|
C 09 087
|
Replacement: Plate washer
|
|
€2.01
|
|
Image number
11
|
|
C 88 206d
C 09 089
|
Sleeve
Bushing for hood hinge on wheel arch
10 120 887 00 49 or 101208870049
|
|
on request
€2.84
|
|
|
C 09 089
|
Replacement: Sleeve
|
|
€2.84
|
|
Image number
|
|
C 88 206
C 88 206
|
Stud bolt for hood hinge
Stud bolt for hood hinge
120 990 04 05 or 1209900405
|
|
on request
on request
|
|
|
Image number
9, 10, 13, 14
|
|
C 88 206i
C 88 206i
|
Hood rubber set
Hood rubber set
10 120 887 00 78 or 101208870078
|
|
€45.00
€45.00
|
|
|
Image number
12
|
|
C 88 206e
C 09 087
|
Plate washer
Disc for hood. to support K.
10 120 887 05 58 or 101208870558
|
|
on request
€2.01
|
|
|
C 09 087
|
Replacement: Plate washer
|
|
€2.01
|
|
Image number
19
|
|
C 88 211a
C 88 211a
|
Bonnet lock lower part
Bonnet lock lower part
10 120 880 03 60 or 101208800360
|
|
€249.70
€249.70
|
|
|
Image number
20
|
|
C 88 212a
C 88 212a
|
Console (for lock)
Console (for lock)
10 120 880 00 75 or 101208800075
|
|
on request
on request
|
|
|
Image number
21
|
|
C 88 214
C 88 214
|
Fastener lower part
Fastener lower part
120 880 02 60 or 1208800260
|
|
€328.90
€328.90
|
|
|
Image number
22
|
|
C 88 218
C 88 218
|
Bonnet lock top part
Bonnet lock top part
10 180 880 01 60 or 101808800160
|
|
on request
on request
|
|
|
Image number
24
|
|
C 88 223
C 88 223
|
Hood release cable
Hood release cable
10 120 880 04 59 or 101208800459
|
|
€82.95
€82.95
|
|
|
Image number
25
|
|
C 88 228
C 88 228
|
Knurled nut
Knurled nut
187 527 00 72 or 1875270072
|
|
€30.45
€30.45
|
|
|
Image number
26
|
|
C 88 229
A 30 084
|
Handle for starter starter cable
Handle for bonnet puller
120 302 08 01 or 1203020801
|
|
on request
€13.00
|
|
|
A 30 084
|
Replacement: Handle for starter starter cable
|
|
€13.00
|
|
Image number
28
|
|
C 30 056
C 30 056
|
Grommet 3-18
Grommet 3-18
186 997 06 81 or 1869970681
|
|
€1.37
€1.37
|
|
|
Image number
29
|
|
C 30 057
C 30 057
|
Clamp
Clamp
186 995 02 20 or 1869950220
|
|
€4.69
€4.69
|
|
|
Image number
30
|
|
C 88 237a
|
Safety hook left
10 120 880 01 64 or 101208800164
|
on request
|
|
Select variant
|
on request
|
|
|
Image number
30
|
|
C 88 236
|
Safety hook left
10 120 880 00 64 or 101208800064
|
€65.00
|
|
€65.00
|
|
|
Image number
32
|
|
C 88 245b
C 88 245b
|
Rubber buffer for bonnet
Rubber buffer for bonnet
000 987 57 40 or 0009875740
|
|
€8.09
€8.09
|
|
|
Image number
50
|
|
C 88 265
C 88 265
|
Front star 180,a,D.190,D,220a,219 all 220S
Front star 180,a,D.190,D,220a,219 all 220S
180 880 03 86 or 1808800386
|
|
€350.00
€350.00
|
|
|
Image number
52
|
|
C 88 267
C 88 267
|
Escutchen for star for W110, W111, W120 Ponton , W121 Ponton, different typs
Escutchen for star for W110, W111, W120 Ponton , W121 Ponton, different typs
10 180 888 02 17 or 101808880217
|
|
€126.00
€126.00
|
|
|
Image number
53
|
|
C 88 268
C 88 268
|
Release spring
Release spring
10 180 888 00 34 or 101808880034
|
|
€2.31
€2.31
|
|
|
Image number
55
|
|
C 88 267f
C 88 267f
|
Rubber pad for Mercedes star on radiator
Rubber pad for Mercedes star on radiator
10 180 888 01 97 or 101808880197
|
|
on request
on request
|
|
|
Image number
40
|
|
C 88 247a
C 88 247a
|
Radiator grill without company logo
Radiator grill without company logo
10 120 880 04 83 or 101208800483
|
|
on request
on request
|
|
|
Image number
42
|
|
C 88 261
C 88 261
|
Emblem for grill
Emblem for grill
10 120 880 00 88 or 101208800088
|
|
€140.00
€140.00
|
|
|
Image number
45
|
|
C 88 266b
C 88 266b
|
Mercedes star
Mercedes star
10 120 888 01 09 or 101208880109
|
|
on request
on request
|
|
|
Image number
46
|
|
C 88 267b
C 88 267b
|
Rossete for Mercedes star
Rossete for Mercedes star
10 120 888 01 17 or 101208880117
|
|
on request
on request
|
|
|
Image number
47
|
|
C 88 267c
C 88 267c
|
Base (for Mercedes star)
Base (for Mercedes star)
10 120 888 00 13 or 101208880013
|
|
on request
on request
|
|
|
Image number
48
|
|
C 88 267d
C 88 267d
|
Rubber underlay
Rubber underlay
10 120 888 00 97 or 101208880097
|
|
on request
on request
|
|
|
Image number
49
|
|
C 88 267e
C 88 267e
|
Washer
Washer
10 120 888 00 12 or 101208880012
|
|
on request
on request
|
|
|
Image number
51
|
|
C 88 266
C 88 266
|
Front star tiltable.
Front star tiltable.
10 180 888 01 09 or 101808880109
|
|
€94.30
€94.30
|
|
|
Image number
60
|
|
C 88 270a
C 88 270a
|
Radiator protection grille
Radiator protection grille
10 120 880 00 85 or 101208800085
|
|
€146.00
€146.00
|
|
|
Image number
61
|
|
C 88 274
C 88 274
|
Mounting spring
Mounting spring
10 120 888 00 34 or 101208880034
|
|
€2.52
€2.52
|
|
|
Image number
62
|
|
C 88 276
C 88 276
|
Mounting sprinhg top + center
Mounting sprinhg top + center
10 120 888 02 34 or 101208880234
|
|
€11.60
€11.60
|
|
|
Image number
63
|
|
C 88 278a
C 88 278a
|
Garnish moulding (Reflectal)
Garnish moulding (Reflectal)
10 120 888 02 21 or 101208880221
|
|
on request
on request
|
|
|
Image number
64
|
|
C 88 281
C 88 281
|
Mounting clip for vertical moulding
Mounting clip for vertical moulding
000 990 05 33 or 0009900533
|
|
€3.78
€3.78
|
|
