20 Engine Cooling for MB 300SE/Cp W112.021 with engine 189.985 Mercedes-Benz
300SE/Coupe W112.021

Chosen model:

Chassis: 112.021
Engine: 189.985
Change vehicle
Change module

Step 5:

Select spare part

Step 5:

Select spare part

in stock
low stock level
currently not in stock, but available for order
no longer available

Pic.	Niemöller part-no.	Designation		Price/unit excl. tax.
Image number		D 20 200 D 20 200	Water pump including gasket Water pump including gasket 186 200 08 20 or 1862000820		€550.00 €550.00
Image number		D 20 200 D 20 200	Water pump including gasket Water pump including gasket 189 200 04 20 or 1892000420		€550.00 €550.00
Image number 110		D 20 257 D 20 257	Magnetic coupling Magnetic coupling 189 200 01 27 or 1892000127		on request on request
Image number 112		D 20 259	Bearing pedestal 189 200 03 28 or 1892000328	on request		Select variant	on request
Image number 112		D 20 259	Bearing pedestal 189 200 05 28 or 1892000528	on request		Select variant	on request
Image number		D 20 261 D 20 261	Snap ring Snap ring 189 994 00 35 or 1899940035		on request on request
Image number 113		D 20 264 D 20 264	Bearring Bearring 000 625 006 203 or 000625006203		€7.25 €7.25
Image number 115		D 20 262	Pulley with shaft 189 200 03 21 or 1892000321	on request		Select variant	on request
Image number 115		D 20 262	Pulley with shaft 189 200 04 21 or 1892000421	on request		Select variant	on request
Image number 117		C 05 089 C 05 089	Seeger Ring Seeger Ring 000 471 017 000 or 000471017000		€1.29 €1.29
Image number 118		D 20 269	O-ring 003 997 83 45 or 0039978345	on request		Select variant	on request
Image number 118		D 20 268	End cover 189 206 00 57 or 1892060057	on request		Select variant	on request
Image number		D 20 270 D 20 270	Retaining ring Retaining ring 000 472 004 000 or 000472004000		on request on request
Image number 122		D 20 271 D 20 271	Fan hub Fan hub 189 200 01 26 or 1892000126		on request on request
Image number 123		D 20 273 D 20 273	Sealing ring Sealing ring 003 997 13 46 or 0039971346		€8.00 €8.00
Image number 124		D 20 270 D 20 270	Retaining ring Retaining ring 000 472 040 000 or 000472040000		on request on request
Image number 125		D 20 274 D 20 274	Angular ball bearings Angular ball bearings 000 628 003 203 or 000628003203		on request on request
Image number 126		C 05 089 C 05 089	Seeger Ring Seeger Ring 000 471 017 000 or 000471017000		€1.29 €1.29
Image number 127		D 20 254 D 20 254	Sealing flange Sealing flange 189 205 00 80 or 1892050080		€6.30 €6.30
Image number 128		D 20 276 D 20 276	Sealing cover Sealing cover 189 205 00 13 or 1892050013		on request on request
Image number 129		C 01 258 C 01 258	Hex. socket screw Hex. socket screw 000 912 006 004 or 000912006004		€0.75 €0.75
Image number 131		C 07 425 C 07 425	Hex. nut Hex. nut 000 934 006 006 or 000934006006		€0.40 €0.40
Image number 135		D 20 278	Retaining plate for belt tensioner 112 200 00 40 or 1122000040	on request		Select variant	on request
Image number 135		D 20 279	Retaining plate for belt tensioner 189 206 02 40 or 1892060240	on request		Select variant	on request
Image number 136		D 13 070 D 13 070	Sealing ring Sealing ring 000 997 23 41 or 0009972341		€1.40 €1.40
Image number 137		D 20 280 D 20 280	Stud/R.sp.+L.b.an Z.-K.gh. Stud/R.sp.+L.b.an Z.-K.gh. 189 206 00 70 or 1892060070		on request on request
Image number 138		D 20 281 D 20 281	Bolt/R.sp.+L.b.an Cyl.kurb.geh. Bolt/R.sp.+L.b.an Cyl.kurb.geh. 189 206 00 74 or 1892060074		on request on request
Image number 139		D 29 082 D 29 082	Disc, push rod on clutch pedal Disc, push rod on clutch pedal 000 125 008 407 or 000125008407		on request on request
Image number 140		D 20 282 D 20 282	Hexagon nut/R.sp.+L.b.an Z.K.gh Hexagon nut/R.sp.+L.b.an Z.K.gh 189 990 04 51 or 1899900451		on request on request
Image number 141		G 75 029 C 32 027	Hex. nut M 8 Hex nut 000 934 008 008 or 000934008008		on request €0.54
	C 32 027	Replacement: Hex. nut M 8		€0.54
Image number 145		D 20 283 D 20 283	Holder/R.sp.+L.b.an Z.kgh. Holder/R.sp.+L.b.an Z.kgh. 189 200 11 40 or 1892001140		on request on request
Image number 146		A 54 225 A 54 225	Rubber grommet Rubber grommet 000 997 22 81 or 0009972281		€1.40 €1.40
Image number 147		A 46 113 A 46 113	Washer for steering lock on carrier Washer for steering lock on carrier 312 990 19 40 or 3129901940		€4.00 €4.00
Image number 149		G 75 029 C 32 027	Hex. nut M 8 Hex nut 000 934 008 008 or 000934008008		on request €0.54
	C 32 027	Replacement: Hex. nut M 8		€0.54
Image number 150		D 20 285	V-belts 000 997 54 92 or 0009975492	€31.10		Select variant	€31.10
Image number 150		D 20 286	Fan belt 13x975 000 997 51 92 or 0009975192	€28.32		Select variant	€28.32
Image number 155		D 20 286a D 20 286a	Blower Blower 188 205 00 06 or 1882050006		on request on request
Image number 156		G 35 010 G 35 010	Hexagon head screw M8x22 DIN 933-8G Hexagon head screw M8x22 DIN 933-8G 000 933 008 114 or 000933008114		€2.20 €2.20
Image number 157		B 03 018 B 03 018	Spring washer Spring washer 000 137 008 202 or 000137008202		€0.30 €0.30
Image number		C 20 146 C 20 146	Engine plate N 202 MN 5 Engine plate N 202 MN 5 900 202 000 700 or 900202000700		on request on request
Image number		A 58 015 A 58 015	Nail Nail 001 476 003 002 or 001476003002		€1.00 €1.00

Please note that the product names may be an automatic translation for which no guarantee can be given.
