47 Fuel System for MB 500SL W107.046 engine 117.964 80-85 Mercedes-Benz
500SL W107.046

Chosen model:

Chassis: 107.046
Engine: 117.964
Change vehicle
Change module

Step 5:

Select spare part

Step 5:

Select spare part

in stock
low stock level
currently not in stock, but available for order
no longer available

Pic.	Designation		Price/unit excl. tax.
Image number 8	F 47 176	Fuel tank 107 470 45 01 or 1074704501	€3,635.76		Select variant	€3,635.76
Image number 8	F 47 176a	Fuel tank / replica (with this tank, the original filter G 47 008 is no longer used - instead, screw the extraction hose directly onto the already mounted nozzle) 107 470 45 01 or 1074704501	€610.00		Select variant	€610.00
Image number 23	F 47 183 F 47 183	Fuel sender unit Fuel sender unit 107 542 08 04 or 1075420804		€245.47 €245.47
Image number 35	F 47 055 F 47 055	Sealing ring for fuel sender unit Sealing ring for fuel sender unit 107 997 13 45 or 1079971345		€1.50 €1.50
Image number 41	G 47 008 G 47 008	Fuel strainer with gasket Fuel strainer with gasket 201 470 04 06 or 2014700406		€36.33 €36.33
Image number 44	D 47 036 D 47 036	Seal ring Seal ring 110 997 01 45 or 1109970145		€5.42 €5.42
Image number 53	F 47 187 F 47 187	Grommet Grommet 123 997 35 81 or 1239973581		€3.97 €3.97
Image number 62	G 25 018 G 25 018	Screw Screw 304 017 008 034 or 304017008034		€3.90 €3.90
Image number 65	D 33 142 D 33 142	Washer, rubber bearing on body-floor Washer, rubber bearing on body-floor 108 990 03 40 or 1089900340		€7.59 €7.59
Image number 74	A 68 032 A 68 032	Cover Cover 110 987 01 45 or 1109870145		€11.03 €11.03
Image number 77	D 47 049	Filler cap 124 470 00 05 or 1244700005	€73.09		Select variant	€73.09
Image number 77	F 47 071	Tank cap Fa. Huf 201 471 01 30 or 2014710130	on request		Select variant	on request
Image number 86	F 47 190 F 47 190	Bins Bins 107 470 07 89 or 1074700789		€1,076.13 €1,076.13
Image number 89	C 54 174 C 54 174	Plug clip nut for fuse box Plug clip nut for fuse box 000 994 25 45 or 0009942545		€2.27 €2.27
Image number 92	G 54 075 G 54 075	Self-tapping screw, conductive connector to holder Self-tapping screw, conductive connector to holder 007 981 004 325 or 007981004325		€22.86 €22.86
Image number 95	G 88 123 G 88 123	Washer 5.3 DIN 9021 Washer 5.3 DIN 9021 009 021 005 205 or 009021005205		€1.05 €1.05
Image number 98	G 47 024 G 47 024	Fuel hose 6mm / sold per meter Fuel hose 6mm / sold per meter 107 476 37 26 or 1074763726		€7.50 €7.50
Image number 101	E 47 006 E 47 006	Clamp 11mm Clamp 11mm 916 033 011 100 or 916033011100		on request on request

Please note that the product names may be an automatic translation for which no guarantee can be given.

in stock
low stock level
currently not in stock, but available for order
no longer available

Fuel tank

F 47 176 €3,635.76

Fuel tank / replica (with this tank, the original filter G 47 008 is no longer used - instead, screw the extraction hose directly onto the already mounted nozzle)

F 47 176a €610.00

Fuel sender unit

F 47 183 €245.47

Sealing ring for fuel sender unit

F 47 055 €1.50

Fuel strainer with gasket

G 47 008 €36.33

Seal ring

D 47 036 €5.42

Grommet

F 47 187 €3.97

Screw

G 25 018 €3.90

Washer, rubber bearing on body-floor

D 33 142 €7.59

Cover

A 68 032 €11.03

Filler cap

D 47 049 €73.09

Tank cap Fa. Huf

F 47 071

Bins

F 47 190 €1,076.13

Plug clip nut for fuse box

C 54 174 €2.27

Self-tapping screw, conductive connector to holder

G 54 075 €22.86

Washer 5.3 DIN 9021

G 88 123 €1.05

Fuel hose 6mm / sold per meter

G 47 024 €7.50

Clamp 11mm

E 47 006

As of ident. no.
042 002002
043 012556
044 034421

Fuel tank

F 47 176 €3,635.76

The original G 47 008 filter is no longer used with this tank - instead, screw the removal hose directly onto the already fitted connection piece

Fuel tank / replica (with this tank, the original filter G 47 008 is no longer used - instead, screw the extraction hose directly onto the already mounted nozzle)

F 47 176a €610.00

As of ident. no.
042 002002
043 012556
044 034421

Fuel sender unit

F 47 183 €245.47

As of ident. no.
023 005010
043 009411

Sealing ring for fuel sender unit

F 47 055 €1.50

As of ident. no.
042 008786
044 065003
045 000319
046 000171

Grommet

F 47 187 €3.97

Up to ident. no.:
023 001000
043 007533
044 004969

Filler cap

D 47 049 €73.09

As of ident. no.
022 006131
023 012983
024 024514
026 000428-001875
042 005114
043 014030
044 051686
046 000001-000170
STATE LOCK NUMBER WHEN ORDERING
045 SWITZERLAND 019228 EXCEPT FOR 014997
UP TO CHASSIS NEW EQUIPMENT 9/82
042 014437 EXCEPT FOR

Tank cap Fa. Huf

F 47 071

As of ident. no.
043 003443 EXCEPT FOR 003852-003894

Bins

F 47 190 €1,076.13

ORDER BY THE METER

Fuel hose 6mm / sold per meter

G 47 024 €7.50

Fuel strainer with gasket

G 47 008 €36.33

Seal ring

D 47 036 €5.42

Screw

G 25 018 €3.90

Washer, rubber bearing on body-floor

D 33 142 €7.59

Cover

A 68 032 €11.03

Plug clip nut for fuse box

C 54 174 €2.27

Self-tapping screw, conductive connector to holder

G 54 075 €22.86

Washer 5.3 DIN 9021

G 88 123 €1.05

Clamp 11mm

E 47 006
