280E Mercedes-Benz w114

Chosen model: Chassis: 114.062 | Engine: 110.981 | Choose different model

Current unit you are viewing: 83 Heating and Ventilation

.product-group-2 .product-group-3 .product-group-7 .product-group-12 .product-group-13 .product-group-14 .product-group-17 .product-group-18 .product-group-20 .product-group-21 .product-group-22 .product-group-23 .product-group-27 .product-group-28 .product-group-65 .product-group-66 .product-group-71 .product-group-72 .product-group-73 .product-group-74 .product-group-88 .product-group-89 .product-group-101 Panel
Pic. Niemöller
part-no.
Designation   Price/unit
excl. tax.
Price/unit
incl. VAT, excl. shipping

2 F 83 003 heat exchangers currently not in stock, but available for order €554.65 €660.04 *
3 F 83 005 Intermediate piece (summer air) no longer available on request on request
0 G 54 134 Sheet metal screw, control unit on holder no longer available on request on request
0 G 68 257 Washer A 6.4 DIN 9021 in stock €0.75 €0.89 *
7 C 72 189 square head screw in stock €3.10 €3.69 *
0 C 07 425 Hex. nut in stock €0.40 €0.48 *
0 G 68 257 Washer A 6.4 DIN 9021 in stock €0.75 €0.89 *
12 F 83 016 blower no longer available on request on request
0 F 83 020 carbon brush set no longer available on request on request
13 F 83 021 Switch 4-fold no longer available on request on request
14 F 83 023 Seal no longer available on request on request
17 C 75 036 rubber sealing ring f. trunk star in stock €0.65 €0.77 *
0 G 88 152 sheet-metal screw in stock €1.43 €1.70 *
0 G 54 079 Screw,Conductor a.Conductor connector no longer available on request on request
18 F 83 026 Rear channel left
F 83 028 Rear channel right
0 G 54 176a Sheet metal screw 4,2x22 in stock €10.50 €12.50 *
20 F 83 032 Defroster nozzle left
F 83 034 Defroster nozzle right
21 F 83 036 waterproofing no longer available on request on request
22 F 83 037 Valve, water drain at front wall currently not in stock, but available for order €4.44 €5.28 *
23 F 83 038 water gutter currently not in stock, but available for order €17.25 €20.53 *
27 C 83 014 sealing ring in stock €3.50 €4.17 *
28 D 83 276 Seal in stock €2.73 €3.25 *
65 F 83 100 Hose between terminal connection H.k.u.Ros. no longer available on request on request
66 D 68 878 expanding rivet in stock €0.53 €0.63 *
71 F 83 110 ball insert currently not in stock, but available for order €53.22 €63.33 *
72 F 83 112 Handle no longer available on request on request
73 F 83 114 corrugated ring no longer available on request on request
74 F 83 115 Hose from heating box to nozzle no longer available on request on request
R76 F 83 117 duct R.L.between heating box and nozzle no longer available on request on request
0 G 68 257 Washer A 6.4 DIN 9021 in stock €0.75 €0.89 *
88 D 83 256 grommet in stock €0.37 €0.44 *
89 F 83 142 Nozzle Hz.-V.u.R.barrel at end cap. no longer available on request on request
0 F 83 143 Hose between preheater and heating box currently not in stock, but available for order €24.32 €28.93 *
101 D 13 247 rubber ring in stock €2.01 €2.39 *
0 D 50 150 water hose 18mm - sold per meter in stock €19.50 €23.20 *
0 F 83 161 hose clip no longer available on request on request
0 D 20 000c Hose clamp 20 - 32 in stock €2.96 €3.52 *
0 D 20 000c Hose clamp 20 - 32 in stock €2.96 €3.52 *
0 D 14 191 hose clip no longer available on request on request
Please note that the product names may be an automatic translation for which no guarantee can be given.
in stock in stock low stock level low stock level currently not in stock, but available for order currently not in stock, but available for order no longer available no longer available
